DHP-1565

Wireless N PowerLine Gigabit Router

$179.99


Wireless N PowerLine Gigabit Router
The D-Link Wireless N PowerLine Gigabit Router (DHP-1565) provides you an all-in-one
solution for the freedom of a Wi-Fi network, the power of blazing fast wired network,
and the flexibility of PowerLine connectivity.


Whole-Home Coverage, No Unsightly Cables
This router works seamlessly with D-Link’s PowerLine AV adapters (sold separately)
to extend your network to anywhere in your home using the electrical wiring already
installed in your walls. Simply connect and power up the Wireless N PowerLine Gigabit
Router to instantly transform every power outlet in your home into a possible network
connection, without the mess of cables. With speeds up to 500Mbps, this PowerLine
router offers a connection fast enough to stream HD videos without so much as a stutter,
and is the perfect solution for accessing your network - and all the devices on it - from
any room in your home.

The Convenience of Wi-Fi and PowerLine, all in one router
The DHP-1565 is a Wireless N 300 router that provides a significantly
faster and farther-reaching wireless signal than outdated Wireless G
routers. D-Link’s Intelligent Antenna Technology makes use of your home’s
environment by bouncing multiple wireless signals off of walls and ceilings
to work around obstructions and help eliminate dead spots. At the same
time, you can use PowerLine in areas where a wired connection would be
beneficial, like streaming media to your entertainment center.

Features:

  • Achieve whole home coverage with this hybrid router that combines Wireless N300, PowerLine 500AV and Gigabit Ethernet for great coverage and performance
  • Fast wired connection with 4 Gigabit Ethernet LANĀ ports and 1 Gigabit Internet Port
  • Easy PowerLine and Wireless Setup with one-button Connect
  • Enhanced Internet Experience with built-in QoS Engine
  • Share a USBĀ printer or storage device with SharePort Technology across your network

• IEEE 802.11n and 802.11g compliant
• Speed up to 500Mbps³ for PowerLine AV network
and up to 300Mbps for wireless network
• Uses your home’s existing electrical wiring by
plugging into power outlets²
• Wi-Fi® Protected Setup™ (WPS) for Simple Push-
Button wireless network configuration
• Built-in QoS Engine enhances Internet experience
• Supports secure wireless encryption using WPA™ or
WPA2™
• Power Saving Mode
• Supports 128-bit AES Encryption For PowerLine
network security
• Common Connect Button for Wi-Fi Protected Setup™
(WPS) and secure PowerLine Network
• Plug & Play installation
• 24/7 Basic installation support4

• 1-Year Limited Warranty5

Standards
• IEEE 802.11n
• IEEE 802.11g
• IEEE 802.3
• IEEE 802.3u
• HomePlug AV
• IEEE 1901


Ethernet Interface
• 4 Gigabit Ethernet Port
• 1 Gigabit WAN Port
• RJ-45 Connector


Maximum PHY Rate for Wireless
• 300 Mbps


Maximum PHY Rate for PowerLine
• 500 Mbps¹


PowerLine Freqency Band
• 2MHz to 70MHz


QoS
• Intergrated QoS prioritizes media
and data
PowerLine Security
• 128-bit AES Encryption


LEDs
• Power
• Internet
• PowerLine

Power Supply
• 100~240VAC, 50/60Hz


Power Saving
• Power saving mode supported
• Compliant with European Energy Using
Product Directive


Operating Temperature
• 30° to 104° F (0° to 40° C)


Operating Humidity
• 10% to 90% non-condensing


Certifications
• FCC Part 15 Class B
• IC
• UL


Dimensions
• 6” x 8” x 1.6”
(15.24cm x 20.32cm x 4.06cm)
Weight
• 0.94 lbs (0.43kg)


Warranty
• 1-Year Limited Warranty5

1 Maximum wireless signal rate derived from IEEE Standard 802.11 specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and
network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless signal range. Wireless range and speed rates are D-Link RELATIVE performance measurements based on the wireless range and speed rates
of a standard Wireless G product from D-Link. Maximum throughput based on D-Link’s 802.11n devices.
2 Power outlets and electrical wiring must all be part of the same electrical system. Certain electrical conditions in your home, such as wiring conditions and configuration may affect the performance of this product. A minimum of two D-Link
PowerLine AV Network Adapters are required to create a network. Connecting this product to a power strip with a surge protector may adversely affect the performance of this product. For best results, plug adapter directly into a power outlet.
3 Maximum throughput based on theoretical transmission PHY rate. Actual data throughput will vary. Network conditions and environmental factors, including volume of traffic and network overhead, may lower actual data throughput rate.
Interference from devices that emit electrical noise, such as vacuum cleaners and hair dryers, may adversely affect the performance of this product. This product may interfere with devices such as lighting systems that have a dimmer switch, short
wave radios, or other powerline devices that do not follow the HomePlug PowerLine Alliance standard.
4 24/7 Basic Installation Support is available only in the USA for the first 30 days from date of original purchase.
5 1-Year Limited Warranty available only in the USA and Canada.
6 Computer must adhere to Microsoft’s recommended system requirements.
7 Software included is not Mac-compatible. 8Latest Software and Documentation available at http://support.dlink.com.
